| 外形尺寸(mm) | 計算系數(shù) | 基本負(fù)荷(KN) | 極限轉(zhuǎn)速(r/min) | 重量(KG) | | d | D | T | C | B | b | D1 | Rsmin | rsmin | e | Y | Y0 | 動 | 靜 | 脂潤滑 | 油潤滑 |
| 150 | 210 | 38.5 | 36 | 31 | | | 2.5 | 2 | 0.27 | 2.2 | 1.21 | 200 | 385 | 1500 | 2000 | 4.56 |
| 150 | 225 | 48.5 | 45 | 38 | | | 3 | 2.5 | 0.39 | 1.5 | 0.85 | 255 | 455 | 1400 | 1900 | 6.85 |
| 150 | 225 | 48 | 48 | 36 | | | 3 | 2.5 | 0.46 | 1.3 | 0.72 | 356 | 610 | 1400 | 1900 | 6.4 |
| 150 | 270 | 49 | 45 | 38 | | | 4 | 3 | 0.44 | 1.4 | 0.76 | 490 | 680 | 1300 | 1800 | 11 |
| 150 | 270 | 77 | 73 | 60 | | | 4 | 3 | 0.44 | 1.4 | 0.76 | 7530 | 1175 | 1200 | 1700 | 18.7 |
| 150 | 320 | 72 | 65 | 55 | | | 5 | 4 | 0.35 | 1.7 | 0.96 | 840 | 1085 | 1100 | 1600 | 25.2 |
| 150 | 320 | 114 | 108 | 90 | | | 5 | 4 | 0.35 | 1.7 | 0.96 | 1275 | 1865 | 950 | 1400 | 42.7 |
| 160 | 220 | 38.5 | 36 | 31 | | | 2.5 | 2 | 0.27 | 2.2 | 1.23 | 215 | 400 | 1300 | 1800 | 3.8 |
| 160 | 240 | 51.5 | 48 | 41 | | | 3 | 2.5 | 0.37 | 1.6 | 0.89 | 400 | 675 | 1100 | 1600 | 7.7 |
| 160 | 290 | 52 | 48 | 40 | | | 4 | 3 | 0.44 | 1.4 | 0.76 | 530 | 730 | 1100 | 1600 | 13.4 |
| 160 | 290 | 84 | 80 | 67 | | | 4 | 3 | 0.44 | 1.4 | 0.76 | 890 | 1420 | 1100 | 1600 | 23.4 |
| 160 | 340 | 75 | 68 | 58 | | | 5 | 4 | 0.35 | 1.7 | 0.96 | 930 | 1210 | 1000 | 1500 | 28.3 |
| 160 | 340 | 88 | 79 | 54 | | | 3.7 | 3.7 | 0.76 | 0.8 | 0.43 | 750 | 1080 | 1000 | 1500 | 30 |
| 160 | 340 | 121 | 114 | 95 | | | 5 | 4 | 0.35 | 1.7 | 0.96 | 1400 | 2230 | 1000 | 1500 | 51.7 |
| 160 | 340 | 87.3 | 79.4 | 50.3 | | | 4.7 | 4.7 | 0.7 | 0.9 | 0.47 | 800 | 1060 | 1000 | 1500 | 40.7 |
| 170 | 230 | 38.5 | 36 | 31 | | | 2.5 | 2 | 0.28 | 2.1 | 1.17 | 255 | 460 | 1400 | 1900 | 4 |
| 170 | 260 | 57.5 | 54 | 46 | | | 3 | 2.5 | 0.31 | 1.9 | 1.07 | 440 | 774 | 1400 | 1900 | 10.1 |
| 170 | 360 | 80 | 72 | 62 | | | 5 | 4 | 0.35 | 1.7 | 0.96 | 1040 | 1360 | 1100 | 1600 | 11.7 |
| 170 | 360 | 127 | 120 | 100 | | | 5 | 4 | 0.36 | 1.7 | 0.93 | 1530 | 2315 | 950 | 1400 | 60.3 |
| 180 | 250 | 45 | 45 | 34 | | | 2.5 | 2 | 0.48 | 1.2 | 0.69 | 335 | 685 | 1000 | 1500 | 6.54 |
| 180 | 280 | 64 | 64 | 48 | | | 3 | 2.5 | 0.42 | 1.4 | 0.78 | 600 | 1035 | 950 | 1400 | 14 |
| 180 | 280 | 64.5 | 60 | 52 | | | 3 | 2.5 | 0.28 | 2.2 | 1.19 | 540 | 900 | 950 | 1400 | 13.4 |
| 180 | 280 | 65 | 63.5 | 48 | | | 2.3 | 2.3 | 0.44 | 1.4 | 0.75 | 490 | 920 | 950 | 1400 | 15.6 |
| 180 | 320 | 57 | 52 | 43 | | | 5 | 4 | 0.45 | 1.3 | 0.73 | 540 | 825 | 950 | 1400 | 17.8 |
| 180 | 320 | 91 | 86 | 71 | | | 5 | 4 | 0.45 | 1.3 | 0.73 | 1040 | 1710 | 950 | 1400 | 30 |
| 180 | 380 | 83 | 75 | 64 | | | 5 | 4 | 0.35 | 1.7 | 0.96 | 1120 | 1500 | 900 | 1300 | 45.5 |
| 190 | 260 | 45 | 45 | 34 | | | 2.5 | 2 | 0.48 | 1.3 | 0.69 | 315 | 690 | 1100 | 1400 | 6.8 |
| 190 | 260 | 45.5 | 42 | 36 | | | 2.5 | 2 | 0.38 | 1.6 | 0.86 | 350 | 700 | 1100 | 1600 | 6.25 |
| 190 | 290 | 51 | 46 | 40 | | | 3 | 2.5 | 0.38 | 1.6 | 0.87 | 350 | 610 | 950 | 1400 | 10.5 |
| 190 | 290 | 64.5 | 60 | 52 | | | 3 | 2.5 | 0.37 | 1.6 | 0.89 | 475 | 880 | 950 | 1400 | 15.3 |
|
